WEIGHTS & MEASUREMENTS
| 59PX | 59P | |
|---|---|---|
| Exterior Length | 21' | 19'19" |
| Exterior Height1</sup | 9'5" | 9' |
| Exterior Width2 | 6'8" | 6'8" |
| Interior Height | 6'2" | 6'2" |
| Interior Width | 6'4" | 6'4" |
| Freshwater Tank Capacity4 (gal.) | 21 | 21 |
| Water Heater Capacity (gal.) | 2.6 | 2.6 |
| Holding Tank Capacity4 — Gray (gal.) | 20 | 20 |
| LP Capacity5 (lbs.) | 24.96 | 24.96 |
| Fuel Capacity (gal.) | 24 | 24 |
| GCWR6 (lbs.) | 11,500 | 11,500 |
| GVWR (lbs.) | 9,350 | 8900 |
| GAWR - Front (lbs.) | 4,629 | 4,629 |
| GAWR - Rear (lbs.) | 5,291 | 5,291 |
| Wheelbase | 159"** | 159" |
| Cassette Toilet Capacity4 (gal.) | 5 | 5 |
| Sleeps9 | 4 | 4 |
CHASSIS
Ram ProMaster® 280-hp, 3.6L V6 gas engine, 6-speed automatic 62TE transmission, 180-amp. alternator
4-wheel ABS brakes
Trailer Hitch6 3,500-lb. drawbar/350-lb. maximum vertical tongue weight
4-pin wiring connector
CAB CONVENIENCES
Radio/Rearview Monitor System 5″ LCD color touch screen, steering wheel controls, color rear camera, USB ports
Cab seats adjustable headrest, slide/swivel/recline, and driver’s side right armrest (59P)
Cab seats armrests, adjustable headrest, slide/swivel/recline (59PX)
Airbags driver and passenger
Cruise control
Digital rearview mirror
Crosswind assist
Blind spot assist (59PX)
3-point seat belts
Power assist steering
Manual adjust mirrors (59P)
Power mirrors w/defrost and turn signal (59PX)
Power door locks w/remote
Power windows
12-volt powerpoints
Sunvisors
Front and cab window privacy panels
INTERIOR
LED ceiling lights
Tinted coach windows
Systems monitor panel
Roof vent (Pop-top sleeping area)
Deluxe powered ventilator fan (59PX without pop-top)
Removable pedestal table
Below floor storage (lounge)
Reading lights
Roof wiring access port
Dinette seating w/3-point seat belts
USB charging ports
Zipped window coverings
Heavy duty vinyl flooring throughout
Ladder
Gear space w/L-track cargo tie down system (59PX)
GALLEY
Laminate countertop
Pull-out countertop extension
2-burner range top w/glass cover
3.0 cu. ft. (12V) single door compressor-driven refrigerator/freezer
Stainless steel sink
Spice rack
BATH
Flexible showerhead
Mirror
Removable clothes rod
Swiveling cassette toilet
Shower curtain
Shower w/wall surround
Tissue holder
BEDROOM
Murphy+ bed w/mattress cover and access to below floor storage
Slat bed system
Deluxe powered ventilator fan
Movable table (only available w/Murphy+ bed option)
Optional Equipment:
Sofa/bed w/two 3-point seat belts (59P)
EXTERIOR
Pop-top sleeping area w/FROLI® sleep system
Porch light w/interior switch (passenger side)
Driver side service light w/interior switch
Assist bar
Side screen door
Rear screen door
Aluminum running board w/logoed tread and pet loop attachment
Rod and privacy screen (provided for rear annex)
Optional Equipment:
Option to remove: Pop-top sleeping area w/FROLI sleep system
HEATING AND COOLING SYSTEM
Truma Combi® Eco Heating System
Coleman®-Mach® 10 NDQ air conditioner w/directional vents (59PX)
Optional Equipment:
13,500 BTU air conditioner (59P without pop-top)
ELECTRICAL SYSTEM
AC/DC load center, 55-amp. converter/charger
Auxiliary start circuit
2 deep-cycle Group 31 batteries (AGM maintenance-free)
Cummins Onan® QG 2800i gas generator (59PX)
Coach battery disconnect system
Automatic dual-battery charge control
30-amp. power cord
220-watt flexible surface solar panel w/controller (w/pop-top)
170-watt solar panel w/controller (without pop-top)
PLUMBING SYSTEM
Exterior wash station (located behind passenger seat)
10′ sewer hose
On-demand water pump
Permanent-mount LP tank w/gauge
Fresh water sight glass
Heated drainage system
Water center control panel includes all control valves, connection points and exterior wash station (located inside right rear door)
Eco-Hot® water system
SAFETY
LP, smoke, and carbon monoxide detectors
Fire extinguisher
Ground fault interrupter
Child seat tether anchor (only available w/sofa/bed option)
Fog lamps (59PX)
WARRANTY7
12-month/15,000-mile basic warranty8
NOTES AND EXCLUSIONS
- The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit. The actual height of our vehicle may vary by several inches depending on chassis or equipment variations. Please contact your dealer for further information.
- Not applicable to this model.
- Not applicable to this model.
- Capacities are based on measurements prior to tank installation. Slight capacity variations can result due to installation applications.
- Capacities shown are tank manufacturer’s listed water capacity (W.C.). Actual filled LP capacity is 80% of listing due to overfilling prevention device on tank.
- Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR and GCWR, as well as adequate trailer brakes. Please refer to the Operator’s Manual of your vehicle for further towing information.
- See separate chassis warranty.
- See your dealer for complete warranty information.
- Sleeping capacity is the maximum based on a specific floorplan.
* Disclaimer: Winnebago recommends following the winter use guidelines and winterization procedures outlined in your owner’s manual whenever camping in freezing conditions.
** Extended wheelbase
Because features, specification, equipment, and options may vary from those highlighted on this website, the buyer is responsible for confirming with the dealer the features, specifications, equipment, and options included in their specific vehicle.
In addition, Winnebago’s program of continuous product improvement may result in changes to vehicle specifications, equipment, model availability, and price without notice.
