WEIGHTS & MEASUREMENTS
| 59G | 59GL | 59K | 59KL | |
|---|---|---|---|---|
| Exterior Length | 21' | 21' | 21' | 21' |
| Exterior Height1</sup | 9'4" | 9'4" | 9'4" | 9'4" |
| Exterior Width2 | 6'9" | 6'9" | 6'9" | 6'9" |
| Awning Length | 13' | 13' | 13' | 13' |
| Interior Height | 6'3" | 6'3" | 6'3" | 6'3" |
| Interior Width | 6'2" | 6'2" | 6'2" | 6'2" |
| Freshwater Tank Capacity4 (gal.) | 18 | 18 | 18 | 18 |
| Water Heater Capacity (gal.) | 2.6 | 2.6 | 2.6 | 2.6 |
| Holding Tank Capacity4 — Black (gal.) | 11 | 11 | 12 | 12 |
| Holding Tank Capacity4 — Gray (gal.) | 14 | 14 | 13 | 12 |
| LP Capacity5 (lbs.) | 25 | 25 | 25 | 25 |
| Fuel Capacity (gal.) | 24 | 24 | 24 | 24 |
| GCWR6 (lbs.) | 11,500 | 11,500 | 11,500 | 11,500 |
| GVWR (lbs.) | 9,350 | 9,350 | 9,350 | 9,350 |
| GAWR - Front (lbs.) | 4,629 | 4,629 | 4,629 | 4,629 |
| GAWR - Rear (lbs.) | 5,291 | 5,291 | 5,291 | 5,291 |
| Wheelbase | 159" | 159" | 159" | 159" |
| Sleeps9 | 2 | 2 | 2 | 2 |
CHASSIS
Ram ProMaster® 280-hp, 3.6L V6 gas engine, 6-speed automatic 62TE transmission, 180-amp. alternator
4-wheel ABS brakes
Stylized aluminum wheels
Trailer Hitch6 3,500-lb. drawbar/350-lb. maximum vertical tongue weight
4-pin wiring connector
CAB CONVENIENCES
Radio/Rearview Monitor System 7″ multimedia touchscreen infotainment center, steering wheel controls, color rear camera, Apple CarPlay®, Android Auto™, Bluetooth®, SiriusXM®, JBL® Speakers and USB ports
Cab seats armrests, adjustable lumbar support, adjustable headrest, and slide/swivel/recline
Airbags driver and passenger front, side curtain, side seat bolster
Cruise control
3-point seat belts
Power steering w/telescoping wheel
Power mirrors w/defrost and turn signal
Power door locks w/remote
Power windows
Digital rearview mirror
Crosswind assist
Blind spot monitoring
12-volt powerpoints
Sunvisors
Front and cab window privacy panels
Carpet floor mat
Appliqué package
SuperSprings® SumoSprings® (front and rear)
Optional Equipment:
Cab seats w/Ultraleather® covering
INTERIOR
24″ HDTV and Bluetooth® soundbar
Pedestal w/pop-up outlets and mount for table
Dinette seating w/3-point seat belts (59G, 59GL)
Amplified digital TV antenna
LED ceiling lights
Blackout cassette shades
Soft vinyl ceiling
Tinted coach windows
Systems monitor panel
Deluxe powered ventilator fan w/rain cover
Removable/adjustable table
Below floor storage
Anything Keeper™ drop down storage baskets
RAM® Tough-Track™ Mounts throughout
Reading lights
Gear bag pocket storage (59G, 59GL)
Roof wiring access port
Insulated rear window zipper coverings
Dual-pane acrylic windows w/screen and blackout cassette shades
Woven floor mat
GALLEY
Corian® countertop
Flip-up countertop extension (59G, 59GL)
Microwave/convection oven w/touch controls (59K, 59KL)
Microwave oven w/touch controls (59G, 59GL)
2-burner range LP cooktop w/glass cover and heat shield (59G, 59K)
Single burner induction cooktop (59GL, 59KL)
Single door 4.3 cu. ft. compressor-driven refrigerator/freezer 12-volt (59K, 59KL)
Two-door 6.0 cu. ft. compressor-driven refrigerator/freezer 12-volt (59G, 59GL)
Stainless steel sink w/Corian sink cover
Cold water filtration system (galley)
Spice Rack
Pull-out countertop extension (59K, 59KL)
BATH
Flexible showerhead
Medicine cabinet
Mirror
Fold-down sink (59K, 59KL)
Toilet w/foot pedal and sprayer
Shower curtain
Shower package w/showerpan
Shower w/wall surround (59G, 59GL)
Stainless steel sink (59G, 59GL)
Tissue holder
Towel bar
Sliding tambour bath door (59G, 59GL)
Two-piece sliding door (59K, 59KL)
Powered roof vent
Wardrobe cabinet (59K,59KL)
BEDROOM
Double bed w/WinnSleep™ system and support leg/step (59G, 59GL)
Twin beds w/WinnSleep system and storage below passenger side (59K, 59KL)
Flex Bed kit (59K, 59KL)
EXTERIOR
Powered patio awning w/LED lighting and Bluetooth control
Porch light w/interior switch
Driver’s side service light
Assist bar w/integrated RAM® Tough-Track™ mount (sliding entrance door)
Assist bar (rear entrance door)
Rear door latch convenience strap
Side screen door w/magnetic closures
Rear screen door
Rod and privacy screen (provided for rear annex)
Aluminum running boards w/logoed tread, ground-effect lighting and pet loop attachment
Bike rack
Movable ladder
Luggage rack
HEATING AND COOLING SYSTEM
Coleman®-Mach® 10 NDQ air conditioner w/directional vents, Bluetooth® control and built-in thermostat with auto mode
Truma Combi® Eco Plus Heating System w/two 850-watt heating elements
ELECTRICAL SYSTEM
Pure3 Energy Management System (59GL, 59KL) 3-module (9,600 usuable watt-hours) lithium-ion energy pack, 3,600-watt inverter, Bluetooth control module, energy pack heating system and a second dedicated alternator powered by the chassis engine
Cummins Onan® QG 2800i gas generator (59G, 59K)
AC/DC load center, 45-amp. converter/charger
Auxiliary start circuit
2 deep-cycle Group 31 batteries (59G, 59K) (AGM maintenance-free)
Coach battery disconnect system
Automatic dual-battery charge control
30-amp. power cord
Exterior TV jack
Exterior AC/DC receptacle
Energy Management System
215-watt solar panels solar charge controller w/junction box and plugs for additional solar panels
1,000-watt pure sine wave inverter (59G, 59K)
Optional Equipment:
Pure3 Energy Management System (59GL, 59KL) 4-module (12,800 usuable watt-hours) lithium-ion energy pack, 3,600-watt inverter, Bluetooth control module, energy pack heating system and a second dedicated alternator powered by the chassis engine
PLUMBING SYSTEM
LPG accessory connection (patio area)
Water center control panel includes all control valves, connection points and exterior wash station w/pump switch
10′ sewer hose
Winterization package w/labeling, water heater bypass valve and siphon tube
On-demand water pump
Permanent-mount LP tank w/gauge
Macerator pump (59G, 59GL gray tank only)
Eco-Hot® water system
Holding tank flushing system
Heated drainage system
SAFETY
LP, smoke, and carbon monoxide detectors
Fire extinguisher
Ground fault interrupter
Fog lamps
WARRANTY7
12-month/15,000-mile basic warranty8
NOTES AND EXCLUSIONS
- The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit. The actual height of our vehicle may vary by several inches depending on chassis or equipment variations. Please contact your dealer for further information.
- Not applicable to this model.
- Not applicable to this model.
- Capacities are based on measurements prior to tank installation. Slight capacity variations can result due to installation applications.
- Capacities shown are tank manufacturer’s listed water capacity (W.C.). Actual filled LP capacity is 80% of listing due to overfilling prevention device on tank.
- Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR and GCWR, as well as adequate trailer brakes. Please refer to the Operator’s Manual of your vehicle for further towing information.
- See separate chassis warranty.
- See your dealer for complete warranty information.
- Sleeping capacity is the maximum based on a specific floorplan.
* Disclaimer: Winnebago recommends following the winter use guidelines and winterization procedures outlined in your owner’s manual whenever camping in freezing conditions.
Because features, specification, equipment, and options may vary from those highlighted on this website, the buyer is responsible for confirming with the dealer the features, specifications, equipment, and options included in their specific vehicle.
In addition, Winnebago’s program of continuous product improvement may result in changes to vehicle specifications, equipment, model availability, and price without notice.
**Base Manufacturers Suggested Retail Price shown. Base price does not include tax, title, license, delivery charges or optional features. Prices are subject to change without notice.
